Low Pressure Fire Suppression Water Mist Spray Nozzle for Bus

Bus Fire Suppression Low-Pressure Water Mist System is composed of nozzle, valve unit, and stainless steel pipe, etc. The working pressure is set to 1.2Mpa. The system has a linkage to the automatic alarm system. It is responsive, stable in flow rate, uniform in water mist, easy for maintenance, has excellent extinguishment characteristics and price performance ratio.
  • OEM
  • OEM
  • $20-50
  • Stainless Steel
  • 1
Availability:
Quantity:

Lead Time:

Quantity(Pieces) 1-50 51-300 >300
Est. Time(days) 7 14 To be negotiated

Low Pressure Water Mist Spray Nozzle Model List:

Serial number Model number Type K Factor working pressure(Mpa) Connector thread(Custom) Number of nozzles
1 DW-T3.5/0.2 Open 3.5 0.2Mpa-1.2Mpa M18*1.5/G1/2 6/7Pcs
2 DW-T4.0/0.2 Open 4.0 0.2Mpa-1.2Mpa M18*1.5/G1/2 6/7Pcs
3 DW-T4.5/0.2 Open 4.5 0.2Mpa-1.2Mpa M18*1.5/G1/3 6/7Pcs
4 DW-T5.0/0.2 Open 5.0 0.2Mpa-1.2Mpa M18*1.5/G1/4 6/7Pcs
5 DW-T5.5/0.8 Open 5.5 0.8Mpa-1.6Mpa M18*1.5/G1/5 6/7Pcs
6 DW-T6.0/0.8 Open 6.0 0.8Mpa-1.6Mpa M18*1.5/G1/6 6/7Pcs
7 DW-T6.5/0.8 Open 6.5 0.8Mpa-1.6Mpa M18*1.5/G1/7 6/7Pcs
8 DW-T7.0/0.8 Open 7.0 0.8Mpa-1.6Mpa M18*1.5/G1/8 6/7Pcs
9 DW-T7.5/0.8 Open 7.5 0.8Mpa-1.6Mpa M18*1.5/G1/9 6/7Pcs
10 DW-T8.0/0.8 Open 8.0 0.8Mpa-1.6Mpa M18*1.5/G1/10 6/7Pcs
11 DW-T8.5/0.8 Open 8.5 0.8Mpa-1.6Mpa M18*1.5/G1/11 6/7Pcs
12 DW-T9.0/0.8 Open 9.0 0.8Mpa-1.6Mpa M18*1.5/G1/12 6/7Pcs
13 DW-T9.5/0.8 Open 9.5 0.8Mpa-1.6Mpa M18*1.5/G1/13 6/7Pcs
14 DW-T10.0/0.8 Open 10.0 0.8Mpa-1.6Mpa M18*1.5/G1/14 6/7Pcs



How To Place A Order?

Inquiry> Drawing> Quote> Sample making> Sample confirm> Produce> Delivery

1.Inquiry:Let us know your requirements or application.

2.Drawing:You can send us drawing or sample

3.Quote:we quote according to your requirements or our suggestions.

4.Sample making:We make the sample and send it to you

5.Sample confirm:You confirms the samples and places deposit for formal order.

6.Produce:we arrange the production.

7.Delivery:We deliver the products to you

1. How long does it take to receive samples?
a) Pattern:30-45days after order
b) Sample:30days after pattern finishing.
c) The lead time is the general production period and does not include the transportation time.

2. Can we visit the factory to conduct an audit?
Yes, you are welcome to visit our partner factory by prior agreement.


Introduction
Bus Fire Suppression Low-Pressure Water Mist System is composed of nozzle, valve unit, and stainless steel pipe, etc. The working pressure is set to 1.2Mpa. The system has a linkage to the automatic alarm system. It is responsive, stable in flow rate, uniform in water mist, easy for maintenance, has excellent extinguishment characteristics and price/performance ratio.
Design Features
  • Very fine droplet size, Class I water mist

  • Major parts include nozzle body, nozzle tips, whirl core, spray orifice, strainer mesh

  • High spray momentum, the good ability for penetration of fire

  • Very fine atomizing droplets, Good dispersion effect

  • Fog-like droplets remain in the air for a long time

Spray Characteristics
  • Spray pattern: Full Cone

  • Spray angles: 120°(other angles optional)

  • Operating pressure:0.2~1.2Mpa

441120
