Features of Mist nozzle
You are here: Home » News » Features of Mist nozzle

Features of Mist nozzle

Views:0     Author:Site Editor     Publish Time: 2021-10-04      Origin:Site

The Mist nozzle is named after its atomized particles are very small and uniform. It has the characteristics of a large area covered by atomized water mist, energy-saving, and fast water mist evaporation effect. It is widely used in the fields of industry, agriculture, and landscape fog. The Mist nozzle has the following characteristics

1. The atomized particles are extremely small and uniform to ensure complete evaporation.

2. Atomized water mist covers a large area. The maximum atomization diameter of the gas-liquid atomization spray gun can reach 3um-4um, which can be more fully mixed with the flue gas, which is beneficial to the cooling of the flue gas and the amount of flue gas. The atomized particles remain basically unchanged throughout the range of water volume changes.

3. Significantly save energy, and can achieve fine atomization under lower air pressure. The gas-liquid atomizing spray gun not only uses low-pressure and low-energy gas and water but also can adjust the flue gas temperature to the set value while ensuring that the humidity is not low. This reduces the amount of flue gas entering the dust collector, and the power consumption of the fan is correspondingly reduced.

4. Ensure that the dust collector exerts the highest efficiency. For the bag filter, because the flue gas temperature is not wet at the bottom, the amount of flue gas is reduced, thereby saving cloth bags. And you can choose low-temperature cloth bags of high quality and low price. For the electrostatic precipitator system, the specific resistance is adjusted to the minimum by cooling and temperature adjustment of the flue gas, thereby improving the efficiency of the electrostatic precipitator.

5. The compressed air consumption is low. Among similar gas-liquid atomizing spray guns, the gas consumption is the lowest.

6. The water volume adjustment range is not large. The gas-liquid atomizing spray gun can automatically adjust the water and gas pressure, and the spray volume can be continuously adjusted between the maximum design flow and the zero position. Such a water volume adjustment range can easily adjust the spray water volume through the adjustment system when the production conditions are unstable, and the atomized particles remain basically unchanged within the entire water volume change range.

7. Strong dust collection capacity, high desulfurization efficiency, small atomized particles, and quickly leaving the nozzle. At a distance of 1.2M from the nozzle, it can still reach 25-30m/s, making the high-speed water mist particles collide effectively and elastically. , So that a considerable part of the dust particles agglomerate.

8. The gas-liquid atomization spray gun has a larger aperture than ordinary nozzles and has excellent anti-clogging performance. In order to ensure that the atomized particles are as small as possible, the diameter of the high-pressure water nozzle is generally not more than 2mm, which is likely to cause fouling and blockage due to factors such as poor water filters. Our gas-liquid atomizing spray gun has 3-8 nozzle holes with a diameter of 6.3mm. Its unique design of a super large spray hole makes it more adaptable to impurity particles in water. For the utilization of river water, industrial circulating water users can reduce the cost of water quality pretreatment.

9. Due to the design of the special atomization tower and spray system, the speed difference and pressure difference formed with the surrounding flue gas is used in the reactor to achieve the most effective mixing of flue gas with fine water droplets, water vapor and reflector. Suitable for desulfurization, removal of HF, HCL, SO2, H2S and out of stock.

10. The additional control system automatically adjusts the water volume of the spray gun according to the change of the flue gas temperature to ensure that the outlet temperature of the dust collector is kept within a proper range, and the control system is stable, reliable and accurate. Evaporative cooling: The best way to cool hot gases and reduce emissions.
